Bosch Rexorth Modular plate system Rexroth

Bosch Rexorth Modular plate system RexrothThe IH15B control modules serves the realization of complete hydraulic controls. They can be fitted and mounted individually. The directional valve modules and seat valve modules can be combined.Using the tank connection modules, the control modules can be directly mounted to the tank cover of the oil tank. Using the modules for external attachment, the control modules can, however, also be installed arbitrarily into every system. The reducing modules allow for attachment of the IH15B modules to IH15A and IH20B modules.The modules have preferably been designed for hydraulic controls for low-flow actuators up to a flow of 30 l/min. They are connected by means of three tie rods.Component series 1XMaximum operating pressure 350 bar
